Place of Origin: | China |
Brand Name: | Thimas |
Certification: | CE,ISO |
Model Number: | T-S2543 |
Minimum Order Quantity: | 1 |
---|---|
Price: | 50000 USD - 80000 USD |
Packaging Details: | Standard packing or according to customers requirement |
Delivery Time: | 50 working days |
Supply Ability: | 10 sets per month |
Voltage: | 380V 50Hz 3phases | Weight: | 15T |
---|---|---|---|
Condition: | New | Dimension(l*w*h): | 7500*1700*1600Mm |
1. Constituent part:
(1)Forming machine: making the material bend and initial machine-shaping, meanwhile, it will bend the material to the silo required radius of curvature.
(2)Bending machine: it will roll cooperate with good molding materials bender seaming together
(3)Load bearing support: Given the right diameter of silo. Lifting of the steel silo enclose the top of load bearing support rollers, it can support the spiral rising silo.
(4)Decoiler: Moving steel coils that put on the decoiler, making steel coils can into forming machine successfully.
(5)Join frame: Joining the load bearing support, locking the required diameter of soil, making the load bearing support stable working.
2.Weight of machine parts:
(1)Forming machine——3300 kg
(2)Bending machine——3550 kg
(3)Decoiler——230 kg
(4)Load bearing support——80kg
(5)Joint Frame——38kg
3.(1) Required thickness of raw material:
A,Galvanized sheet——1.5---3mm
B,Dark steel sheet——1.5---3mm
C,Chromated nickel steel sheet——1.5---2.5mm
D,Plastic coatings steel sheet——1.5---3mm
(2) Raw material width: 495mm
(3) Finished width: 350---370mm
(4) Diameter: 4m——25m
(5) Electrical equipment power: 9x3kw=27kw
